Model:DSO-D / DSO-DF Series
Laboratory hot air oven are suitable for various applications in the fields of agricultural, medical and industrial researches for heating, drying, sterilizing and baking in laboratories, hospitals and industries. PID Temperature Control provides automatic compensation after load changes, setting changes or door opening for excellent accuracy. Natural convection heat distribution combines with the adjustable air vents to provide excellent uniformity. Double wall construction, fiberglass insulation provided on 5 sides as well as between inner and outer walls, and silicon rubber door sealing reduce heat loss and power drain. Stainless steel interior chamber and shelves are corrosion resistant, durable and easy to clean. Powder coating exterior is beautiful, durable, and corrosion resistant.
Download Add to inquiry
Features

• Hot Air Oven can be made in customers' specifications.

• Simple keypad input allows easy temperature setting.

• LED digital display enables users to monitor the chamber temperature at any given moment.

• Visual alarm indicator alerts users of abnormal conditions if the chamber temperature exceeds the setting points by 10℃.

• The temperature can be controlled and maintained to 200℃.

• Ovens feature a smoked see-thru window to view contents without opening.

• Shelves can be adjustable.

• Quality certification: ISO 9001, ISO 13485

Specification
Model DSO-200D/
DSO-200DF
DSO-300D/
DSO-300DF
DSO-500D/
DSO-500DF
DSO-1500D/
DSO-1500DF
DSO-3000D/
DSO-3000DF
Convection DSO-D series are natural convection/ DSO-DF series are forced convection
Working temperature Ambient + 5 ~ 200 degree℃
Time mode Continuous mode / timed mode (1~999 hours or 1~999 minutes)
Capacity (Liters) 20 30 50 150 300
Chamber dimension
(mm) (WxDxH)
300x310x230 325x310x315 380x365x390 625x510x500 625x510x1000
Power watts 500W 700W 1000W 1400W 2500W
Overall dimension
(mm) (WxDxH)
412x420x500 425x420x610 480x475x695 725x620x795 725x620x1465
Accessory 2 shelves
Power supply AC 110V 50/60Hz (220V 50/60Hz available)
